DETAIL
- Item No
0000001012
- Type
- Vertical Machining Center
- Maker
- MORI SEIKI
- Model
- NV6000DCG/50
- MFG Year
- 2008
- Movie
- Specification
- Comment
- Controller: MSX-701Ⅲ (FANUC-31iA）
Table size: 1,000 × 600 mm
Max. load capacity: 800 kg
Travel X: 900 Y: 600 Z: 450 mm
Distance from spindle end to nose: 400～850 mm
Spindle speed: 8,000 rpm
Tool shan : BT50 （2‑surface constraint）
ATC: 230 stations
Required floor space : 4,605×4,250 mm
Machine height : 3,169 mm
Machine weight : 11,000 kg
High column (200 mm)
Sub-table (120 mm)
Rotary table (with tailstock)
1-axis additional interface
Through-spindle coolant discharge pressure: 7.0 Mpa
Click on the picture for larger view.
*The machine condition shall be understood "AS IS", regardless of specifications and photos in the machine list.
